CMCP315FG-12, 12 Triaxial Accelerometer BNC Junction Box
The CMCP315 Series Triaxial Accelerometer Switchable BNC Junction Boxes are multiple channel connection centers designed for terminating the outputs of triaxial accelerometers while allowing simultaneous data collection. They are normally located in a close proximity to a machine to reduce wiring costs as well as to provide a convenient and safe location to access sensor signals. The CMCP315 Series BNC Boxes are circuit board based with a removable front cover plate to ease installation. The cover plate hides all internal wiring to limit exposure for increased protection.
Features:
▪ Available for 2 to 16 Triaxial Accelerometer Inputs
▪ 3 BNC Outputs (X, Y and Z)
▪ Optional Quick Connect Output
▪ IP66, NEMA 4X Rated Fiberglass Enclosure
▪ Heavy Duty Terminal Strips
▪ Quick Release Door Latches
▪ Top Plate Safety Cover
▪ Optional IP68 Breakthrough Cord Grips
Specifications:
| Input | |
| Connection: | Screw Terminals 22-14 AWG |
| Termination: | Bare Wire or Spade Lugs (#6 Screw Size) |
| Isolation: | Electrically Isolated |
| Output | |
| Connection: | Three 50Ω BNC Jacks (Female), Marked X,Y, Z |
| Switch | 1 Switch per 4 Triaxial Sensors. (16 Triaxial Sensors would use 4 Switches) |
| Switch Type: |
3 Pole make before Break |
| Material/Size: | Compression Molded 16"x14"x8" Fiberglass |
| NEMA Rating: |
NEMA 4X |
| IP Rating: |
IP66 |
| Temperature Range: |
-55 to +85°C (-67 to +185°F) |
| Door Closure |
Quick Release Snap Latches with Lock |
Contact us at (214) 238-0493 for full specifications.
