CMCP700S-CV Case Vibration Transmitter

The CMCP700S-CV (Case Vibration) accepts an Accelerometer or Velocity Sensor Input. 4ma Constant Current Power for the sensor is provided. Standard input is 100 mv/g or 100 mv/in/sec (4 mv/mm/sec). The CMCP700S-CV provides an output in either Acceleration (g’s) or Velocity (in/sec, mm/sec).

With a Velocity Sensor Input either a Velocity or Displacement (mils, um) output is available. Both ISO Standard and ISO Low Frequency are DIP switch selectable. RMS or Peak Signal Detection is selectable. A Buffered Output signal is available on the screw terminals, or the signals can be connected to a din rail mount BNC Module like the CMCP300E.

Features:

• Accelerometer or Velocity Input
• Acceleration, Velocity or Displacement Output
• Single Level of Integration
• RMS or Peak Detection
• English or Metric Selectable
• ISO Standard 10 Hz - 1 kHz or
• ISO Low Frequency 2 Hz - 2 kHz
• Selectable Filters
• Buffered Output Terminal
• 4 mA Sensor Power
• Slimline DIN Rail Mount
