CMCP760T, Triaxial Accelerometer, Side Exit, 100mV/g per axis

The CMCP760T Side Exit Triaxial Accelerometer is the ideal accelerometer for most types of rotating equipment. The CMCP760T is lightweight and can be use for route based measurements or for permanently installed applications. The sensor is designed so that cross wiring will not harm the internal components and provides protection against ground loops. The CMCP760T is waterproof and can be hosed down or submersed when using the proper extension cable such as the CMCP605 series.

Features: Sensitivity (Per Axis): 100mV/g ±10% Frequency Response (±3dB): 0.8Hz to 15kHz (48 to 900k CPM) Dyanamic Range: ±80 g, peak Settling Time: 2 Seconds Mounting: 1/4"-28 UNF Captive Bolt Power Requirements: 18-30 VDC Temperature Range: -67 to 266°F (-55 to 130°C) Case Material: 316L Stainless Steel Connector: 4 Pin M12 Warranty: Lifetime Quality Warranty
