FLIR E5 Wi-Fi Infrared Camera with MSX (120x90)

Discontinued. This item has been replaced by the FLIR E6 PRO IR Camera, Extended Temperature Range & WiFi.

FLIR E5 with Wi-Fi is a powerful temperature measurement tool that's perfect for diagnosing electrical, mechanical, and building problems. Thanks to the 10,800 (120x90) pixel infrared detector, you can find hidden issues quickly and easily, and record accurate temperature measurements across your target. The built-in Wi-Fi can help streamline your workload, allowing you to upload and share images and data through the FLIR Tools mobile app.




SPECIFICATIONS

Overview

Accuracy

±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)

Detector Type

Uncooled microbolometer

Field of view (FOV)

45° × 34°

IR Resolution

120 × 90 pixels

List of Contents

•Infrared camera •Hard transport case •Battery (inside camera) •USB cable •Power supply/charger with EU, UK, US and Australian plugs •Printed documentation

Multi Spectral Dynamic Imaging (MSX)

IR image enhanced with visible camera detail

Object Temperature Range

–20°C to 250°C (–4°F to 482°F)

Packaging Size

385 × 165 × 315 mm (15.2 × 6.5 × 12.4 in)

Thermal Sensitivity/NETD

<0.10°C (0.27°F) / <100 mK
