Nova-PRO 500 Kit, LED Stroboscope/Tachometer

Nova-Pro is a series of powerful portable visual inspection and speed measurement tools. We have combined all the features of our hand held LED stroboscopes together with a full function laser tachometer to create a compact, ergonomic and extremely powerful two in one predictive maintenance tool. The stroboscope light source is made up of twelve LED’s which are extraordinarily bright yet extremely efficient allowing cool continuous operation and extremely long battery life (up to 19 hours on a single charge). Continuous operation is also possible with the optional AC adapter.

Nova-Pro 500 Kit: Has all the features of the 300 and adds an additional standard battery pack, remote laser docking station, phase delay,time delay, virtual slow motion and latching carry case.

Product includes: Stroboscope, Two Battery Packs, Remote Laser Docking Station, NIST Certificate and User Manual and latching carry case.

Features: Optional Laser tachometer Super bright LED's Integral/removable laser module Splash resistant IP54 enclosure 1/4" x 20 tripod mount Remote Laser Docking Station Removable rechargeable Li-ion battery

Applications:

• Visual running inspections of: Fan blades, motors, shats, gears, rollers, webs, belts, sheaves, chains, sprockets and much more without having to shut down your process


• Diagnose alignment issues


• Determine speed of rotatng equipment using strobe or built in laser tachometer


• Troubleshoot high speed automaton processes by placing them in virtual slow motion


• Print quality inspection


• Textile processing inspection


• Phase reference for balancing

SPECIFICATIONS: Nova-Pro 500

Flash Range (FPM/RPM):	60 to 999,999
Display:	6 digit numeric and 5 digit alphanumeric display with touch keypad. High Contrast blue background/white characters with back light
Accuracy/Resolution:	0.001% of setting or +/- Lsd/6 digits to 0.001
Light Source:	12 High Output LED Array
Flash Duration:	Adjustable to 14 degrees, 3000 μ seconds max
Light Output:	5500 LUX at 6000 fpm, 12 in (20cm) 2° Duty Cycle, Max Light Output 30000 LUX
Color Temperature:	Aproximately 6200° K
External Triggers In/Out:	TTL (12Vdc Max) Input. Provides 3.3Vdc
Tachometer Mode:	0-999,999 with integral laser or external input
Programmable Memory:	Yes, 10 setpoints
Internal Phase Shift:	Yes
Phase Delay Degrees:	-360 to 345 Degrees
Time Delay Milliseconds	-50.000 to 50.000 Msec
Virtual RPM (Slow Motion)	Yes
Operating Time:	Standard Battery Pack: 9.5 Hours typical (6000 fpm 2° Duty Cycle
Power Supply:	Qty of 2, Rechargeable Li-ion Battery with 115/230V, 50/60 Hz Charging Station
Weight:	1.4 lbs with standard battery pack
Size (H x W x D):	9.5 x 3.75 x 5.5 in. (241 x 94 x 140 mm)
Housing Material:	ABS
Housing Rating:	IP58
