Track-It™ Vacuum/Temperature Data Logger

Monarch Instrument’s Track-It™ Vacuum/Temperature Data Logger are compact, battery-powered, stand-alone devices that can record up to 64,000 pressure/ambient temperature samples and are available in a wide variety of pressure ranges.

Battery and USB cable are included along with our free downloadable Track-It™ DataLogger PC Software and Track-It™ Transporter Android app!

All models are available with a NIST Traceable Certificate!

These units are also available with various diaphragm seals. Contact Monarch Instrument for details.

Detailed Description

The Track-It™ Vacuum/Temperature Data Logger is a battery-powered, stand-alone, watertight, compact data logger that can record up to 64,000 samples. It can be configured to record both vacuum and ambient temperature or either parameter alone to maximize data storage space. The unit is easily configured using the free downloadable Track-It™ DataLogger Software; simply connect the included USB cable to the logger and an open USB port on your PC and the Track-It™ DataLogger Software automatically identifies the logger.

Configure the unit to start or stop recording immediately, at a predetermined time and date, or only when an alarm condition is sensed. The sample storage rate can be set from 1 sample every 2 seconds up to 1 sample every 24 hours. The onboard data storage is nonvolatile so data will not be lost in the event of a depleted battery.

The Track-It™ Vacuum/Temperature Data Logger can be ordered in vacuum ranges of 0 to -380 and 0 to -760 Torr. The logger is packaged in a rugged submersible (IP67) 316L stainless steel housing and has a standard ¼” NPT fitting.

Typical Uses

• Industrial Processes
• Food Processing
• Water Supply Line
• Hydrant Water Pressure
• Household Water Pressure
• Building Supply Pressure
• Municipalities
• Oil and Gas
• Petrochemical
• Compressors
• Pumps
• Water and Wastewater
• Vacuum Furnaces

Features

• Rugged IP67 316L stainless steel enclosure
• Programmable start/stop time and sample rates
• Up to 64,000 data samples per recording session
• High accuracy and precision, ASME Grade 3A
• USB Interface (cable included)
• Powerful interactive Track-It™ DataLogger Software package (free download)
• Track-It™ Transporter App available for direct data access with Android devices (using On-The-Go cable)
• Multiple alarm setpoints
• Ambient temperature range: -4 °F to 185 °F (-20 °C to – 85 °C)
• Available Torr ranges: 0 to -380 and 0 to -760
• 150% overrange protection
• ¼” NPT male connection
• Compact size
• Lithium battery included
• Accurate internal clock (1 minute/year)
• NIST Traceable Certificate available

Track-It™ DataLogger  Software

Track-It™ DataLogger Software is a powerful Windows-based software package that is available for use with every Track-It Data Logger. It allows for easy setup, retrieval, interpretation, and export of the recorded data. Simply connect your data logger to an open USB port and begin communicating immediately.

Advanced features include:

• Real-time data view and data retrieval when connected via USB
• Delayed recordings, fixed duration recordings by time or number of samples, multiple record times, manual record by button press, record on alarms
• Sample rates from once every 2 seconds to once every 24 hours; instantaneous, average, maximum or minimum values
• Two Alarms: high or low, latched or momentary, and record under these alarm conditions
• Display of data graphically, digitally, or tabular formats with alarm indication
• Export user-selected data in CSV formats for import into Excel®; filter data to be exported

This software is compatible with Windows 7/8/10/11.

Track-It™ Transporter App for Android Devices

All Track-It™ Vacuum/Temperature Data Loggers are compatible with the free Track-It™ Transporter Android application. The app allows you to use your Android device to start/stop recording and transfer data using a USB On-The-Go cable.

The Track-It™ Transporter App is available for free on Google Play.
